F thread DTH Drilling Tools 50mm 60mm OD High Steel DTH Drill Pipes for Rock
In DTH drilling, the rock drilling bit is a continuation of the shank, which the rock drill piston strikes directly. Since the piston is in direct contact with the drill bit, little energy is lost. This gives DTH drilling a nearly constant penetration rate regardless of hole length.
DTH drilling enables drillers to reach hole depths that are double of what top hammer drilling can do. This is possible with the use of DTH Pipes and DTH Subs.
• High grade steel used on thread area and main drill pipe body
• Automated welding process used in joining the thread area and main drill pipe body
Applications
• Underground mining
• Quarry benching operations
• Water well drilling
Competitive Advantage
High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance
Specifications:
| Special Thread Drill Pipe |
| Item | Diameter | Length | Wall thickness | Thread | Drill machine |
| Inch | mm | mm |
| 1 | 3 1/2 | 89 | 4000 | 6 | 2 1/2" Z | ECM695/760/780 |
| 2 | 3 1/2 | 89 | 2700 | 8 | 2 1/2" Z PIN |
| 3 | 3 1/2 | 89 | 2740 | 8 | 3 1/2" API REG Box 2 1/2" Z PIN |
| 4 | 4 | 102 | 4000 | 8 | 3 1/2" API REG Box 2 1/2" Z |
| 5 | 4 | 102 | 2440 | 8 | 2 1/2" Z |
| 6 | 4 | 102 | 4000 | 14 | 2 1/2" Z PIN |
| 7 | 4 | 102 | 2740 | 8 | 3 1/2" API REG Box 2 1/2" Z PIN |
| 8 | 4 1/2 | 114 | 6100-9150 | 8 | 3" BECO | DM-H, DMM-2, DMM-3, DM30/45/50/L, T4W, T4BH, RD20 |
| 9 | 4 1/2 | 114 | 6100-9150 | 10 | 3" BECO |
| 10 | 4 1/2 | 114 | 6100-9150 | 12 | 3" BECO |
| 11 | 5 | 127 | 7620-10670 | 10 | 3 1/2" BECO |
| 12 | 5 | 127 | 7620-10670 | 12 | 3 1/2" BECO |
| 13 | 5 | 127 | 7620-10670 | 14 | 3 1/2" BECO |
| 14 | 5 | 127 | 7620-10670 | 18 | 3 1/2" BECO |
| 15 | 5 1/2 | 140 | 7620-10670 | 9 | 3 1/2" BECO |
| 16 | 5 1/2 | 140 | 7620-10670 | 10 | 3 1/2" BECO |
| 17 | 5 1/2 | 140 | 7620-10670 | 12 | 3 1/2" BECO |
| 18 | 5 1/2 | 140 | 7620-10670 | 18 | 3 1/2" BECO |
| 19 | 6 1/4 | 159 | 9144 | 14 | 4" BECO |
| 20 | 6 1/4 | 159 | 1500-9500 | 10 | 4" BECO |
| 21 | 6 1/4 | 159 | 10670 | 20 | 4" BECO |
| 22 | 7 | 178 | 7620 | 14-25 | 4 1/2" BECO |
| 23 | 7 | 178 | 9144 | 14-25 | 4 1/2" BECO |
| 24 | 7 | 178 | 10670 | 14-25 | 4 1/2" BECO |
| 25 | 7 5/8 | 194 | 7620 | 14-25 | 5 1/4" BECO |
| 26 | 7 5/8 | 194 | 9144 | 14-25 | 5 1/4" BECO
|
Delivery time and Package
Delivery time: around 15-20days
Package: Carton or Wooden Box/Based on customers requirements
Our Services
KSQ Technologies (Beijing) Co. Ltd. is a company that shall cater to the needs of the construction and mining industries, with consideration on providing solutions to the following unique problems:
- Hazardous environment
- Acts, regulations, and other government guidelines that has to be followed
- Significant differences in the way people work, mostly due to physical constraints
- Avoiding downtime on major equipment which can cost tens of thousands of dollars per hour. The best solution with the most reasonable cost is a significant driver.
Company Information
KSQ Technologies (Beijing) Co. Ltd. is a diversified enterprise based in Beijing, China, offering a portfolio of products that help contribute to a better bottom line and increase workplace safety for the construction and mining industries.
KSQ Technologies (Beijing) Co. Ltd. has significant experience and know-how in the supply of materials, components, finished goods, specially designed/engineered equipment, and services from China. The company caters to medium to large scale clients who are doing projects and capital expansion, as well as to firms who require support with consumable products, maintenance, and repair operations. Our operations are based on the unique expertise of our people and knowledge with customer processes.
Our portfolio includes:
Consumables used in the mining and construction industries
Equipment used in the mining and construction industries
Spare parts used for the equipment we sell for the mining and construction industries
Green technologies, such as products that reduce electric consumption or use alternate sources of energy (solar, wind, etc.)
